Marine science: research vessels and technology

Information on the research vessels owned and operated by Marine Scotland Science (MSS).


Main activities:

Operational in:

Launched:

Capabilities:

Fisheries Research

West Coast

2008

Fisheries Research (single, twin, pelagic/demersal trawling and scallop dredging) hydrographic sampling, surveying and camera work

Class:

MCA Category 1 - 150 miles offshore - Safety of Small Workboats and Pilot Boats - A Code of Practice Hull Construction to SFIA, Machinery and outfit to SCMSS

Endurance:

14 days minimum

Builder/Designer:

Macduff Ship Design Ltd

Dimensions:

Length Overall

27.00m



Length on Loadline

23.95m



LBP

23.55m



Breadth Moulded

8.80m



Amidships Depth Moulded

4.30m

Speed:

Trial speed 10.3 knts at 100%




Cruise speed 8 knts



Bollard Pull:

Minimum 11.5 tonnes



Crew:

8



Scientists:

5



















Technical Information

Capacities:

Tonnage

163.47



Oil Fuel

45,274 litres



Fresh Water

15,200 litres



Water Ballast

20,000 litres



Sewage Plant

4,000 litres

Propulsion Machinery:

Main Engines

2 x Mitsubishi S6R MPTK



Rating

2 x 630 BHP @ 1600 RPM



Gearboxes

2 x Reintjes WAF 364L



Ratio

4.92:1



Propellers

2 x fixed pitch, 5 blade



Diameter

1800mm open



Bo-thruster

Thrustmaster 711mm dia 4 blade - 93kw



Stern Thruster

Thrustmaster 711mm dia 4 blade - 93kw



Rudders

2 x high performance



Main Generators

2 x Scania D112 62 EMS 10.6F -220kw



Harbour Generators

1 x Mitsubishi 6D16T -97kw

Laboratories:

Wet Lab Area

12.5 sq m



Dry Lab Area

11.5 sq m

Electrical Supplies:

415v 3ph 50hz




240v 1ph 50hz




24v DC




240v stabilised clean system



Deck Machinery:

3 x Split trawl winches

810m x 20mm wire - RAPP



2 x Auxy trawl winches

100m x 16mm wire - RAPP



Slip ring winch

700m x 30mm cable - RAPP



Slip ring winch

600m x 8.1m cable - RAPP



Anchor windlass

3.5T pull - double - RAPP



Hydro wire winch

400m x 8mm - 1.2T pull- RAPP



Net sounder winch

700m cable - Svendborg



Gilson winch

3.0T pull - RAPP



Knuckle boom crane

Triplex - 18 t/m



Power block crane

Triplex - 10 t/m



Net drum

Split type - 8.0T pull



Portable net drum

Single type - 3.0T pull

Data Processing Equipment:

Ship-Wide fast Ethernet



Fibre optic network



General purpose PCs



Scientific computers



Colour inkjet printers



Thermosalinograph

 Communications

Navigational Equipment:

2 x Band Arpa Radars - JRC 5310/6
Cargo winch - 1.5T pull

1 x Gamma frame - 3.0T SWL – Odim



2 x GPS Simrad GN33D



2 x Sodena Mini ECDIS Chart Plotter



1 x Simrad AP50 Autopilot



2 x Simrad Dual GC80 Gyrocompass



1 x Simrad ES60 Echosounder 50/200 kHz



1 x Suzuki S1800-MBB/H800 Searchlight Sonar 80 kHz



1 x Skipper EML 224 Electromagnetic Log



2 x Wet Lab Extension Monitors for EK60



1 x Simrad EK60 Split Beam 38 kHz



1 x Simrad EK60 Split Beam 120 kHz



1 x Simrad EK60 Split Beam 200 kHz



1x Simrad AI50 AIS system



1 x Seatex MRU H Motion Sensor



1 x Kongsberg Synchronishing Unit



1 x Simrad Hoistable Transducer Unit

Communications:

1 x Sailor 4000 HF SSB 150w PEP



2 x Sailor RT5022 VHF with DSC



4 x Simrad AX50 GMDSS Portable VHF



2 x Simrad EP50 EPIRBs



2 x Simrad SA50 SARTs



1 x Simrad MS55 Fleet 55 Sat System



1 x Skipper Taiyo TF711 Weather Fax



1 x Airmar Weather Station



1 x Cellphone System



1 x Internal Vingtor ACM M PABX & PA System



1 x CCTV System - 5 cameras

Position-Keeping System:

1 x Kongsberg C-Joy Joystick Control System linked to: Gyro Compass, wind, DGPS speed, thrusters, propellers, steering gear and autopilot

Trawl-Monitoring System:

1 x Rapp PTS Pentagon Auto Trawl System
1 x Scanmar Trawl Monitoring System

Noise and Vibration:

Extensive use of noise reducing insulation, flexibly mounted machinery, balanced propellers to minimise noise.

Workboat:

An Allay Duck/ERACO aluminium workboat 5.5m with twin 50 HP outboards and launching davit.
